Ribbon Plus
C0039WDI05000
The code C0039WDI05000 will be valid as of March 2025. You can still continue with this code or use the 82209 code valid until March 2025.Indoor / Flex Lights
LED Strip | 700 topLED 96 W DC 24 V
19.2 W/m | 2222 Lm/m
| IP | IP20 |
|---|---|
| Optic | Diffused |
| CCT | 3000 K |
| CRI | >90 |
| Delivered lumens | -- |
| Installation position | Wall lights, Ceiling |
| Control | |
| Source Type | topLED |
Technical description
Single emission led strip for indoor application. The warm white LED light source with a diffused light distribution topled LED with CCT of 3000 K and a CRI >90.
The device body and features a white finish. The ingress protection degree is IP20; the total weight is of 0.09 kg. The power supply driver is not provided and is to be ordered separately.
The total absorbed power is 0 W. The power supply cable is included and features a 2x 0.3 m length.
The device features protection class III and can be wall lights or ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
