Ribbon
C0046WDI05000
The code C0046WDI05000 will be valid as of March 2025. You can still continue with this code or use the C00510WHWDI code valid until March 2025.Indoor / Flex Lights
LED Strip | 1 topLED 108 W DC 24 V
21.6 W/m | 2341 Lm/m
| IP | IP20 |
|---|---|
| Optic | Diffused |
| CCT | 3000 K |
| CRI | 95 |
| Delivered lumens | -- |
| Installation position | Wall lights, Ceiling |
| Control | |
| Source Type | topLED |
Technical description
Single emission led strip for indoor application. The warm white LED light source with a diffused light distribution is composed of 800 stripled LEDs with CCT of 3000 K and a CRI 95; the source luminous flux is 11403 lm, with a 105.6 lm/W nominal luminous efficacy.
The device body is made of technopolymer and features a white finish. The ingress protection degree is IP20; the total weight is of 0.17 kg. The power supply driver is not provided and is to be ordered separately.
The total absorbed power is 108 W. The power supply cable is included and features a 0.2 m length.
The device features protection class III and can be wall lights or ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
