LED Strip | 1 topLED 192 W DC 48 V

9.6 W/m | 993.1 Lm/m

IP
IP20
Optic
Diffused
CCT
2700 K
CRI
90
Delivered lumens
--
Finishes
White
Installation position
Wall lights, Ceiling
Control
Source Type
topLED

Single emission led strip for indoor application. The super warm white LED light source with a diffused light distribution is composed of 2600 stripled LEDs with CCT of 2700 K and a CRI 90; the source luminous flux is 19862 lm, with a 103.4 lm/W nominal luminous efficacy.

The device body is made of technopolymer and features a white finish. The ingress protection degree is IP20; the total weight is of 1.6 kg. The power supply driver is not provided and is to be ordered separately.

The total absorbed power is 192 W. The power supply cable is included and features a 0.2 m length.

The device features protection class III and can be wall lights or ceiling-mounted.

Compliant with the EN 60598-1 standard and its specific provisions.

Electronics

Code 99784

Stormshield - On/Off Driver 48V 150W 3.13A | Switching Driver 180~295V AC / 255~417V DC 60 W

FamilySwitching Driver
IPIP67
OperationCV
Stormshield - On/Off Driver 48V 150W 3.13A |   Switching Driver 180~295V AC / 255~417V DC  60 W
.zip

Code 99785

Stormshield - On/Off Driver | On/Off Driver 100~305V AC / 142~431V DC 240 W

FamilyOn/Off Driver
IPIP65
OperationCV
Stormshield - On/Off Driver |   On/Off Driver 100~305V AC / 142~431V DC  240 W
.zip

Code 83177

Lumiquad - Mono CV DMX/RDM 1ch - 1-78 W DC - 6.5A 12V / 1-156 W DC 6.5A 24V / 1-312 W DC - 6.5A 48V | Push and Simply Dim Controller

FamilyController
IPIP10
OperationCV
Lumiquad - Mono CV DMX/RDM 1ch - 1-78 W DC - 6.5A 12V / 1-156 W DC 6.5A 24V / 1-312 W DC - 6.5A 48V |  Push and Simply Dim  Controller
.zip

Code C-E400003

DALI-2 PUSH Driver - 1-150 W DC stripLED - 3.2A 48V 150W | Push and Simply Dim Controller

FamilyController
IPIP67
OperationCV
DALI-2 PUSH Driver - 1-150 W DC stripLED - 3.2A 48V 150W  |  Push and Simply Dim  Controller
.zip
